Wago
862-1503
Single- and multi-pole terminal strip
Manufacturer part number: 862-1503
Serie: Series 862
Type: 862-1503
EAN-code: 4044918509473
SKU Omnical: 1202311
Stock: 0.
Estimated lead time: 9 days *
PreOrder
XNQ
€
2,62
per item
€
2,13
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
862-1503 Wago Single- and multi-pole terminal strip
Wago Single- and multi-pole terminal strip 4-draads apparaataansluitklem zonder PE-contact PE-N-L1 zwart
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Explosion-tested version 'Ex e'
No
Connectable conductor cross section fine-strand without cable end sleeve
(mm²)
0.5 - 4
Connectable conductor cross section fine-strand with cable end sleeve
(mm²)
0.75 - 2.5
Connectable conductor cross section solid-core
(mm²)
0.5 - 4
Width
(mm)
36
Connectable conductor cross section multi-wired
(mm²)
0.5 - 4
Rated current In
(A)
32
Rated voltage
(V)
500
Type of electrical connection 1
Spring clamp connection
Type of electrical connection 2
Spring clamp connection
Connection position
Sideways
Number of poles
3
Number of clamp positions per pole
4
Mounting method
Other
Material insulation body
Thermoplastic
Operating temperature
(°C)
105 - 105
Inflammability class of insulation material according to with UL94
V0
Width/grid dimension
(mm)
36
Height at lowest possible mounting height
(mm)
21.4
Length
(mm)
35
Closing plate required
No
Colour
Black
Transparent
No
Height
(mm)
35
Halogen free
Yes
Depth
(mm)
22.3
Stock and logistics
Height
0.1 m
Width
0.65 m
Depth
0.35 m
Packaging
box
Weight
5.2 kg
HS code
85369010
Country of Origin
DE
