Philips
8718699455880
Downlight/spot/floodlight
Manufacturer part number: 8718699455880
Serie: CoreLine
Type: Schijnwerper
EAN-code: 8718699455880
SKU Omnical: 1251611
Stock: 0.
Estimated lead time: 11 days *
PreOrder
ZEN
€
462,00
per item
€
352,97
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
8718699455880 Philips Downlight/spot/floodlight
Philips Downlight/spot/floodlight BVP125 LED80-4S/740 PSU OFA52 ALU C1KC3
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Lamp type
LED not exchangeable
Suitable for number of lamps
28
Lamp holder
None
Type of control gear
LED operating device current-controlled
With control gear
Yes
Width
(mm)
265
Nominal voltage
(V)
220 - 240
Suitable for through-wiring
No
Material housing
Aluminium
Surface finishing
Other
Colour housing
Grey
Reflector
None
Light sharing
Asymmetric
Beam angle
Wide beam 41-80°
Length
(mm)
340.5
Height/depth
(mm)
67.4
Protection class
I
Degree of protection (IP)
IP66
Impact strength
IK08
Luminaire with limited surface temperature, sign "D“
No
With movement sensor
No
With light source
Yes
Suitable for wall mounting
Yes
Suitable for suspended mounting
No
Suitable for ceiling mounting
No
Suitable for traverse mounting
Yes
Suitable for pedestal/floor mounting
Yes
Suitable for light-track mounting
No
Suitable for clamp-mounting
No
Adjustability
Swivelling
With light sensor
No
Type of dimming
Not dimmable
Nominal current
(mA)
629 - 629
Max. system power
(W)
57
Colour temperature
(K)
4000 - 4000
Voltage type
AC
Rated luminous flux according to IEC 62722-2-1
(lm)
8000
Colour of light
White
Colour rendering index CRI
70-79
Suitable for surface mounting
Yes
Suitable for built-in mounting
No
Suitable for low voltage cable system
No
Surface protection
Powder coating
Material cover
Glass transparent
Surface brushed
Yes
LED nominal current at constant current
(mA)
762 - 762
Dimming depending on control gear
No
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming DSI
No
Dimming potentiometer (integrated)
No
Dimming GPRS
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off
No
Dimming phase cut-on
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
No dim function
Yes
Light distributor
Diffuser lens/optic/panel
Light outlet
Direct
Total harmonic distortion
9.4
Rated life time L80/B10 at 25 °C
(h)
75000
Rated ambient temperature according to IEC62722-2-1
(°C)
25 - 25
Luminous flux
(lm)
8000 - 8000
Luminous intensity
(cd)
861
Power factor
0.94
Type of wiring
Ending
Number of poles
3
Conductor cross section
(mm²)
1.5
Connectable conductor cross section
(mm²)
7 - 14
Connection type
Insulation displacement connector
Emergency power supply integrated
No
Luminaire efficacy
(lm/W)
144
Suitable for workplace according to EN 12464-1
Yes
Covering of the luminaire with thermally insulating material possible
No
Filament test according to IEC 60695-2-11
650 °C - 30 s
Photobiological safety according to EN 62471
RG1
Colour consistency (McAdam ellipse)
SDCM3
Unified Glare Ratio (UGR)
0
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Dimming DALI-2
No
Flickering value Pst LM
0.06
Stroboscope effect value SVM
0.09
Exchangeable control gear
Yes
Lumen maintenance at median useful life of 100,000 h at 25 °C ambient (tq)
(%)
96
Failure rate at median useful life of 100,000 h at 25 °C ambient (tq)
(%)
10
Constant light output (CLO)
No
Colour temperature adjustable
No
Luminous flux adjustable
No
Beam angle adjustable
No
Max. number of luminaires per miniature circuit breaker B16
8
Max. number of luminaires per miniature circuit breaker C16
13
Suitable for wall mounting
Yes
D
Operation by Bluetooth
No
Reflector colour
Other
Stock and logistics
Height
0.085 m
Width
0.369 m
Depth
0.4 m
Packaging
box
Weight
5.5 kg
HS code
94054239
Country of Origin
ES
