Philips
8718699163174
Ceiling-/wall luminaire
Manufacturer part number: 8718699163174
Serie: CoreLine
Type: Waterdicht armatuur
EAN-code: 8718699163174
SKU Omnical: 1516123
Stock: 0.
Estimated lead time: 25 days *
PreOrder
ZEN
€
165,00
per item
€
126,06
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
8718699163174 Philips Ceiling-/wall luminaire
Philips Ceiling-/wall luminaire WT120C G2 LED40S/840 PSU TW1 WEC L1200
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Suitable for wall mounting
Yes
Suitable for suspended mounting
Yes
Suitable for ceiling mounting
Yes
Suitable for built-in mounting
No
Suitable for surface mounting
Yes
Width
(mm)
80
Lamp type
LED not exchangeable
With light source
Yes
Lamp holder
Other
Suitable for number of lamps
1
Lamp power at multiwatt
Not applicable
Type of control gear
LED operating device current-controlled
With control gear
Yes
Type of dimming
Not dimmable
Suitable for emergency lighting
No
Emergency unit integrated
No
Nominal voltage
(V)
220 - 240
Nominal current
(mA)
140 - 160
Colour temperature
(K)
4000 - 4000
Material housing
Plastic
Surface finishing
Matt
Colour housing
Grey
Suitable for light line configuration
No
Material cover
Plastic matt/satinized
Suitable for workplace according to EN 12464-1
No
Type of grid
None
Reflector
White
Light sharing
Symmetric
Beam angle
Extreme wide beam >80°
Light outlet
Direct
Length
(mm)
1215
Height/depth
(mm)
76
Built-in height/depth
(mm)
1215
With movement sensor
No
With light sensor
No
Protection class
I
Degree of protection (IP)
IP65
Impact strength
IK08
Luminaire with limited surface temperature, sign "D“
Yes
Covering of the luminaire with thermally insulating material possible
Yes
Ambient temperature
(°C)
-20 - 35
Filament test according to IEC 60695-2-10
850 °C - 5 s
Max. system power
(W)
29.5
With air slots
No
Voltage type
AC
Rated luminous flux according to IEC 62722-2-1
(lm)
4000
Colour of light
White
Colour rendering index CRI
80-89
Surface protection housing
Untreated
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming DSI
No
Dimming potentiometer (integrated)
No
Dimming GPRS
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off
No
Dimming phase cut-on
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
Dimming depending on control gear
No
Operation by Bluetooth
No
No dim function
Yes
Light distributor
Diffuser lens/optic/panel
Colour consistency (McAdam ellipse)
SDCM3
Rated life time L80/B50 at 25 °C
(h)
47000
Rated life time L90/B50 at 25 °C
(h)
22000
Rated ambient temperature according to IEC62722-2-1
(°C)
-20 - 35
Emergency power supply integrated
No
Filament test according to IEC 60695-2-11
850 °C - 30 s
Luminaire efficacy
(lm/W)
136
Power factor
0.86
Type of wiring
Through wiring included
Number of poles
3
Conductor cross section
(mm²)
2.5
Connection type
Screwed terminal
Total harmonic distortion
20
Photobiological safety according to EN 62471
RG0
Unified Glare Ratio (UGR)
25
Dimming DALI-2
No
Flickering value Pst LM
1
Stroboscope effect value SVM
1.6
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Exchangeable control gear
Yes
Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)
(%)
80
Failure rate at median useful life of 50,000 h at 25 °C ambient (tq)
(%)
5
Max. number of luminaires per miniature circuit breaker B16
36
Max. number of luminaires per miniature circuit breaker C16
60
Constant light output (CLO)
No
Colour temperature adjustable
No
Luminous flux adjustable
No
Beam angle adjustable
No
Suitable for wall mounting
Yes
E
Compatible with Casambi
No
Stock and logistics
Height
0.09 m
Width
0.09 m
Depth
1.25 m
Packaging
box
Weight
1.6 kg
HS code
94051140
Country of Origin
HU
