Philips
8718696378328
Luminaire for streets and places
Manufacturer part number: 8718696378328
Serie: Digistreet
Type: Straatverlichtingsarmatuur
EAN-code: 8718696378328
SKU Omnical: 2465410
Stock: 0.
Estimated lead time: 32 days *
PreOrder
ZEJ
€
612,00
per item
€
594,25
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
8718696378328 Philips Luminaire for streets and places
Philips Luminaire for streets and places BGP762 LED169-/740 I DS50 DGR 62
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Mounting method
Side entry
Lamp type
LED exchangeable
Lamp holder
None
Material housing
Aluminium
Width
(mm)
361
Colour housing
Grey
Material cover
Glass transparent
Max. lamp power
(W)
98
Nominal voltage
(V)
220 - 240
Type of control gear
LED operating device current-controlled
With control gear
Yes
Degree of protection (IP)
IP66
Adjustable optics
No
Suitable for spigot size
(mm)
62 - 62
Impact strength
IK09
Protection class
I
With light source
Yes
Length
(mm)
860
Surface protection
Powder coating
Coated
Yes
Voltage type
AC
Nominal current
(mA)
429 - 468
Remote control
None
With radio control
No
Constant light output (CLO)
No
With light regulation program control
No
With connection cable
No
Rated luminous flux according to IEC 62722-2-1
(lm)
14960
Colour of light
White
Colour temperature
(K)
4000 - 4000
Colour rendering index CRI
70-79
LED nominal current at constant current
(mA)
549 - 549
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming DSI
No
Dimming potentiometer (integrated)
No
Dimming GPRS
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off
No
Dimming phase cut-on
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
No dim function
Yes
Light distributor
Diffuser lens/optic/panel
Colour consistency (McAdam ellipse)
SDCM5
Rated life time L80/B10 at 25 °C
(h)
100000
Luminaire with limited surface temperature, sign "D“
No
Rated ambient temperature according to IEC62722-2-1
(°C)
-40 - 50
Max. system power
(W)
98
Luminaire efficacy
(lm/W)
153
Power factor
0.99
Height/depth
(mm)
107
Type of wiring
Ending
Number of poles
2
Conductor cross section
(mm²)
2.5
Connection type
Push-in clamp
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Exchangeable control gear
Yes
Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)
(%)
98
Lumen maintenance at median useful life of 100,000 h at 25 °C ambient (tq)
(%)
96
Failure rate at median useful life of 50,000 h at 25 °C ambient (tq)
(%)
5
Failure rate at median useful life of 100,000 h at 25 °C ambient (tq)
(%)
10
With light sensor
No
Max. number of luminaires per miniature circuit breaker B16
8
Max. number of luminaires per miniature circuit breaker C16
13
Operation by Bluetooth
No
Stock and logistics
Height
0.15 m
Width
0.38 m
Depth
0.975 m
Packaging
box
Weight
11.371 kg
HS code
94054239
Country of Origin
PL
