Eaton
170705
Earth leakage circuit breaker
Manufacturer part number: 170705
Serie: xEffect
Type: FRBMM-B16/1N/003-A
EAN-code: 4015081674626
SKU Omnical: 2537280
Stock:
31 items.
Delivery time: 1-2 business days.
InStock
M88
€
184,58
per item
€
119,98
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
170705 Eaton Earth leakage circuit breaker
Eaton Earth leakage circuit breaker Aardlekautomaat (RCBO) FRBmM, 1P+N, 16A, B-kar., 30mA, 10kA, A-type
Datasheet
Number of poles (total)
2
Number of protected poles
1
Rated current
(A)
16
Rated fault current
(A)
0.03
Release characteristic
B
Concurrently switching neutral conductor
Yes
Leakage current type
A
Rated short-circuit breaking capacity according to EN 60898
(kA)
10
Rated short-circuit breaking capacity according to IEC 60947-2
(kA)
15
Rated voltage
(V)
240
Current limiting class
3
Frequency
50 Hz
Over voltage category
3
Pollution degree
2
Width in number of modular spacings
2
Built-in depth
(mm)
75.5
Degree of protection (IP)
IP20
Suitable for flush-mounted installation
No
Surge current capacity
(kA)
0.25
Voltage type
AC
Anti-nuisance tripping version
No
Rated insulation voltage Ui
(V)
500
Rated impulse withstand voltage Uimp
(kV)
4
Rated short-circuit breaking capacity according to EN 61009
(kA)
10
Rated short-circuit breaking capacity Icn according to EN 61009-1
(kA)
10
Disconnection characteristic
Undelayed
With interlocking device
No
Ambient temperature during operating
(°C)
-25 - 40
Connectable conductor cross section solid-core
(mm²)
1 - 25
Connectable conductor cross section multi-wired
(mm²)
1 - 25
Flush-mounted installation
No
Stock and logistics
Height
0.075 m
Width
0.037 m
Depth
0.086 m
Packaging
item
Weight
0.207 kg
HS code
85362010
Country of Origin
RO
