Concord
2059080
Downlight/spot/floodlight
Manufacturer part number: 2059080
Serie: Beacon LED Wallwash
Type: BEACON WW LED 4K L3 BLK
EAN-code: 5025768590803
SKU Omnical: 4132560
Stock:
9 items.
Delivery time: 1-2 business days.
InStock
X20
€
382,00
per item
€
278,48
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
2059080 Concord Downlight/spot/floodlight
Concord Downlight/spot/floodlight BEACON WW LED 4K LS3 zwart
Datasheet
Suitable for number of lamps
1
Type of control gear
Electronic ballast
With control gear
No
Width
(mm)
170
Nominal voltage
(V)
220 - 240
Material housing
Aluminium
Colour housing
Black
Reflector
None
Beam angle
Open beam/diffuse
Length
(mm)
85
Height/depth
(mm)
175
Protection class
I
Degree of protection (IP)
IP20
Impact strength
Other
Luminaire with limited surface temperature, sign "D“
No
With movement sensor
No
With light source
Yes
Suitable for suspended mounting
No
Suitable for ceiling mounting
No
Suitable for traverse mounting
No
Suitable for pedestal/floor mounting
No
Suitable for light-track mounting
No
Suitable for clamp-mounting
No
With light sensor
No
Suitable for lamp power
(W)
0 - 0
Max. system power
(W)
48
Colour temperature
(K)
4000 - 4000
Voltage type
AC
Rated luminous flux according to IEC 62722-2-1
(lm)
4089
Colour of light
White
Colour rendering index CRI
90-100
Suitable for surface mounting
No
Suitable for built-in mounting
No
Suitable for low voltage cable system
No
Material cover
Other
Surface brushed
No
LED nominal current at constant current
(mA)
0 - 0
Dimming depending on control gear
No
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming DSI
No
Dimming potentiometer (integrated)
No
Dimming GPRS
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off
No
Dimming phase cut-on
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
No dim function
Yes
Light distributor
None
Light outlet
Direct
Total harmonic distortion
0
Rated life time L70/B50 at 25 °C
(h)
100000
Rated ambient temperature according to IEC62722-2-1
(°C)
0 - 0
Luminous flux
(lm)
4089 - 4089
Power factor
0.98
Built-in width
(mm)
0
Built-in height/depth
(mm)
0
Built-in length
(mm)
0
Conductor cross section
(mm²)
0
Connectable conductor cross section
(mm²)
0 - 0
Emergency power supply integrated
No
Luminaire efficacy
(lm/W)
85
Covering of the luminaire with thermally insulating material possible
No
Filament test according to IEC 60695-2-11
None
Photobiological safety according to EN 62471
RG1
Unified Glare Ratio (UGR)
0
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Dimming DALI-2
No
Exchangeable control gear
No
Lumen maintenance at median useful life of 35,000 h at 25 °C ambient (tq)
(%)
0
Constant light output (CLO)
No
Colour temperature adjustable
No
Max. number of luminaires per miniature circuit breaker B16
0
Max. number of luminaires per miniature circuit breaker C16
0
Suitable for wall mounting
No
Built-in diameter
(mm)
0 - 0
E
Operation by Bluetooth
No
Stock and logistics
Height
20 cm
Width
19.5 cm
Depth
25 cm
Packaging
box
Weight
1.94 kg
HS code
94051190
