2CDS253103R0324
Miniature circuit breaker (MCB)
Manufacturer part number: 2CDS253103R0324
Serie: System pro M compact
Type: S 203 C32 NA
EAN-code: 4016779532501
SKU Omnical: 1049729
Stock:
3 items.
Delivery time: 1-2 business days.
InStock
ZQU
€
191,00
per item
€
133,70
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
2CDS253103R0324 ABB Components Miniature circuit breaker (MCB)
ABB Components Miniature circuit breaker (MCB) 6 kA Automaat 3p+N C kar 32A
Datasheet
Release characteristic
C
Number of poles (total)
4
Rated current
(A)
32
Rated voltage
(V)
400
Voltage type
AC
Current limiting class
3
Concurrently switching neutral conductor
Yes
Over voltage category
3
Pollution degree
3
Width in number of modular spacings
4
Built-in depth
(mm)
69
Additional equipment possible
Yes
Degree of protection (IP)
IP20
Number of protected poles
3
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
(kA)
6
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
(kA)
6
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
(kA)
20
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
(kA)
10
Frequency
(Hz)
50 - 60
Suitable for flush-mounted installation
No
Rated insulation voltage Ui
(V)
440
Rated impulse withstand voltage Uimp
(kV)
4
Ambient temperature during operating
(°C)
-25 - 55
Connectable conductor cross section multi-wired
(mm²)
0.75 - 25
Connectable conductor cross section solid-core
(mm²)
0.75 - 35
Explosion-proof
No
Flush-mounted installation
No
Power loss
(W)
14.8
Stock and logistics
Height
0.08 m
Width
0.092 m
Depth
0.078 m
Packaging
Package
Weight
0.5 kg
HS code
85362010
